Midco Adapto Pilot Assembly Options
1190100 Adapto Pilot with Spark and Flame Rod - Natural/LP
"Long Pilot"
134040 Ground Rod
134100 Flame Rod Assembly
134200 Spark Rod Assembly
134103 Pilot Bag Assembly - Natural or 134104 Pilot Bag Assembly - LP
(I.C.E. Assy #712800, FR #562762, SR #562761, GR #562763)
1190850 Adapto Pilot with Spark and Flame Rod - Natural/LP
"Brut Pilot"
136003 Flame Rod Assembly
134206 Spark Rod Assembly
134103 Pilot Bag Assembly - Natural or 134104 Pilot Bag Assembly - LP
(I.C.E. Pilot #712826, FR #562826, SR #562825)
*** OBSOLETE ***
1190800 Adapto Pilot with Spark and Flame Rod
"Short Pilot"
136003 Flame Rod Assembly
134206 Spark Rod Assembly
(I.C.E. FR #562826, SR #562761)
1200100 Adapto Pilot with Spark Rod and UV - Natural/LP
"Long Pilot w/ UV"
134200 Spark Rod Assembly
322645 UV Scanner Tube
134103 Pilot Bag Assembly - Natural or 134104 Pilot Bag Assembly - LP
1200350 Adapto "Brut" Pilot with Spark Rod and UV - Natural/LP
"Brut Pilot w/ UV"
134203 Spark Rod Assembly
322645 UV Scanner Tube
134103 Pilot Bag Assembly - Natural or 134104 Pilot Bag Assembly - LP
1220800 Adapto Pilot for Remote Flame Rod
136003 Flame Rod
(I.C.E. Assy #712831, FR 562826)
1240800 Adapto Pilot For Remote UV
322645 UV Scanner Tube
134103 Natural Gas
Adapto Pilot Bag Assembly:
(2) 845106 Electrode Sleeve
(1) 840807 Anlge Snap Connector (Spark Rod)
(1) 840808 Angle Snap connector (Flame Rod)
(1) Pilot Elbow. No Orifice
134104 Propane Gas
Adapto Pilot Bag Assembly:
(2) 845106 Electrode Sleeve
(1) 840807 Anlge Snap Connector (Spark Rod)
(1) 840808 Angle Snap connector (Flame Rod)
(1) 495707 Propane Pilot Elbow (#58 drill - 0.42)
322645 UV Scanner Tube
GTO-15 Wire 14 AWG
15000 volt
00055.85.01
Used for both Ignition Wire and Flame Rod Wire
Sold by the foot.
